Accusys A08S4-PS 8-Bay Tower RAID System With Single Power Supply(Accusys A08s4 Ps 8 Bay Tower Raid System With Single Power Supply)

Accusys A08S4-PS 8-Bay Tower RAID System with Single Power Supply

You must have experienced this issue while editing your data storage is not able to store all of your creativity. You are panicking, don’t know where to get (and are not willing to spend THAT much money) a second storage while you are burning the midnight oil, and expanding the storage is not an instant option either. You have no choice but to spend a large amount of money on a second storage. We heard you, and we have come out with a solution for you.

A08S4-PS, the 8-bay tower of ExaSAN Family, dedicates itself to those who don’t want to spend extra money and time on a second storage. Moreover, you can expand as you need.

PCIe 3.0 On A08S4-PS
Higher Bandwidth, Higher Performance
A08S4-PS uses PCIe 3.0 technology. It can reach up to 1500 MB/s transfer speeds. This works just perfectly for solo editing.

A08S4-PS With JBOD
Expand as You Need
When your work space needs more than what a tower can offer, you can easily expend it with up to 3 JBODs – meaning the capacity can go up to 320 Terabytes if necessary (by using 10TB HDD).

A08S4-PS On Mac
Link up Your Workflow with C2M
A08S4-PS is compatible with Windows, Linux and MAC. Use our C1M adapter to convert PCIe channel to Thuderbolt 3.0, then you are ready to connect it to a MAC device easily.

Technical Specifications

System Type
8-bay Tower RAID system
Host Interface
PCIe 3.0
Data Transfer Rate
32 Gb/s
Disk Interface
SAS / SATA * 8
Disk Type
3.5″ / 2.5″ / SSD
RAID Level
0, 1, 5, 6, 0+1, JBOD
Cache Memory
2G DDRlll 1866 with ECC-protected
JBOD Expansion
JBOD * 3
Operating Temperature
0 deg C ~ 40 deg C
Storage Temperature
-20 deg C~ 70 deg C
Operating Humidity
5%~85%, Non-condensing
RAID Controller Functions
Online RAID Set Expansion and RAID LEVEL Migration
Online bad block data recovery and reallocation
Online disk scrubbing with data refresh and parity
Disk health monitorning by S.M.A.R.T
Array Roaming and Drive Traveling
Mirror Snapshot for fast backup and restore
Disk Lag Proof Technology to guarantee disk timely response
Equalization Mode to smooth the performance of sequential I/Os and reduce large fluctuation
Management
Java-based RADIGuard X GUI
Event log saving in text file for quick trobleshooting
Event notification by email (SMTP)
LED indicator for RAID & disk drives status in front
400W (A08S4-PS: Single or A08S4-PS+: Redundant). 110V~240V power supply
Two 12cm x 12 cm Fan with Smart Fan Control feature
Dimensions
L:369mm, W:175mm, H:394.6mm
Weight
13.64kg / 30 lbs
