ADJ Aria X2 IPC Wireless DMX Transceiver With Wired Digital Communication Network(Adj Aria X2 Ipc Wireless Dmx Transceiver With Wired Digital Communication Network)

Unleash the potential of your lighting arrangements with our state-of-the-art ADJ Aria X2 IPC Wireless DMX Transceiver With Wired Digital Communication Network. This controller is designed for maximum flexibility and convenience, featuring a single DMX universe and supporting various connectivity options like 900MHz, 2.4 GHz WiFi, and Bluetooth for seamless integration with a range of lighting fixtures. Setting up your lighting has never been simpler, with configuration options available through an upcoming app or the user-friendly front panel interface. Its sturdy IP65 housing ensures durability, enabling you to use it confidently indoors and outdoors.

Supported protocols encompass DMX (with RDM planned for future updates), Bluetooth 5.2, our unique Aria X2 Mesh Protocol, and Aria X2 Serial Protocol, providing unmatched compatibility and adaptability. With advanced RF features such as interference mitigation through CSMA and adaptive frequency hopping, as well as Over-The-Air updates, this controller delivers reliable performance in any setting. For seamless connectivity, the controller includes 900MHz and 2.4GHz antennas, DMX 5-pin XLR input and output, and outdoor locking power input and output. Power is not a concern with universal AC100-240V compatibility and low power consumption of 2.2W for efficient operation. Safety is paramount, with a T1.25A/250V power fuse included.

Crafted to withstand the demands of professional use, the controller boasts an IP65 enclosure, front panel digital screen, and M12 threads for secure mounting. Compact yet durable, the controller measures 6.46″ (163.95mm) in length, 8.48″ (215.30mm) in width, and 1.66″ (42mm) in height, weighing only 2.7lbs (1.23kgs). Step into the future of lighting control and fixture management with our Aria X2 IPC wireless DMX controller.

Key Features

• DMX Universe available for single use
• Supports wireless connectivity through 900Mhz, 2.4 GHz WiFi, and Bluetooth
• Configuration options available through an upcoming App or the front panel
• Enables wireless communication between DMX and Wireless devices
• Equipped with IP65 Housing for protection against dust and water

Technical Specifications

Supported Protocols:
DMX (RDM is planned for future software release)
Proprietary 802.15.4
Aria X2 Mesh Protocol
Bluetooth 5.2 (BLE)
Aria X2 Serial Protocol (This is our proprietary serial protocol for communicating with a variety of fixtures.)
RF Characteristics:
Frequency range
2404-2480 MHz
863-870 MHz (EU)
902-928 MHz
Radio module: Aria X2
Interference mitigation
CSMA
Adaptive frequency hopping (on the roadmap)
OTA updates
Connectors:
900MHz Antenna
2.4GHz Antenna
DMX: 5-pin XLR Input and Output
Outdoor Locking Power Input and Output
Power:
Power Input: AC100-240V 50/60Hz
Power Consumption: 2.2W (19mA) @ 120V/60Hz, 2.2W (10mA) @ 230V/50Hz
Power Fuse: T1.25A/250V. (5 x 20mm)
Physical:
IP65 Enclosure
Front panel digital screen
M12 Threads
Max ambient operating temp range: -4°F to 113°F (-20°C to 45°C)
Max operating humidity: <75%
Storage temperature: 77°F (25°C)
Dimensions and Weight:
Length: 6.46″ (163.95mm)
Width: 8.48″ (215.30mm)
Height: 1.66″ (42mm)
2.7lbs (1.23kgs.)
