ADJ Focus Spot 4Z Pearl 200W Moving Head Spot Fixture(American Dj Focus Spot 4z Pearl 200w Moving Head Spot Fixture)

American DJ Focus Spot 4Z Pearl 200W Moving Head Spot Fixture

The Focus Spot 4Z Pearl sits at the top of range of the popular Focus Series moving heads from ADJ Lighting. The Focus Spot 4Z Pearl is powered by a brilliant 200W cool white LED engine and is equipped with motorized focus and zoom (11 ~ 22-degree zoom), and has a white exterior housing. Its designed for temporary live events and fixed installations in nightclub, stages or churches. It is professionally fit with one GOBO wheel with 6 rotating/replaceable GOBOS, 8 vibrant colors plus white, and 2 prism wheels (one 5-facet linear and one 6-facet circular).

Key Features

• Motorized Focus
• Motorized Zoom: 11 ~ 22-degrees plus 16-bit Fine Zoom
• 2 Prism FX: Rotating 5-facet Linear & rotating 6-facet Circular
• 0-100% smooth dimming
• Various strobe speeds
• USB firmware update port
• 2 cooling fans
• White exterior housing

Technical Specifications

Color Wheel
8 dichroic colors + white
GOBO Wheel
6 aluminum GOBOs + open
All GOBOs removable & rotatable
GOBO Shake Effect
GOBO size: 23mm (outer); 19mm (viewable); 0.5mm (thickness)
Prism Wheel
Prism Wheel 1: Rotatable 5-facet Linear
Prism Wheel 2: Rotatable 6-facet Circular
Prism Indexing
Control
3 DMX Channel Modes: 16/18/22 Channels
Color LCD display with 6-summary function menu
Data In/Out: 3-pin DMX
Power In/Out: Locking powerCON (Daisy chain 4 units @ 120V; 10 units @ 240V)
Control Mode: DMX512 or internal programs
6 Dimming Curve Modes: Standard, Stage, TV, Architectural, Theatre, Stage 2
0-100% smooth dimming
Various strobe speeds
USB firmware update port
With Wired Digital Communication Network
Pan/Tilt
Pan
540 & 630 degrees
Tilt
270 degrees
Dimensions & Weight
Dimension
18” x 10.97” x 7.15” / 457 x 279 x 182mm
Weight
23 lbs. / 10 kg.
What’s Included
Omega Bracket
6 ft/3M powerCON power cable
Safety Cable
