ADJ FOCUS SPOT 6Z 300W Cool White LED Moving Head(Adj Focus Spot 6z 300w Cool White Led Moving Head)

ADJ FOCUS SPOT 6Z 300W Cool White LED Moving Head

The Focus Spot 6Z is powered by a brilliant 300W cool white LED engine that produces vibrant, saturated colors and is equipped with motorized focus, zoom (9~28-degree zoom), Iris and two prisms. It is designed for temporary live events and fixed installations in nightclubs, stages or churches. It is professionally fit with two GOBO wheels (7 GOBOs per wheel), two COLOR wheels, each with 7 vibrant colors plus white, and 2 rotating/indexable prisms, (one 6-facet linear and one 6-facet circular). It also has two frost effects (heavy frost and light frost).

The Focus Spot 6Z has locking power In and out connectors to daisy chain the power, as well as 3-pin and 5-pin DMX In/Out to transmit a DMX signal from one fixture to the next. It also has RJ45 In/Out connections to control with ArtNet and KlingNet. There is a USB firmware update port built-in plus advanced control options such as: 16-bit fine pan and tilt, multiple DMX control modes, and 6 different dimming options. The Focus Spot 6Z offers a robust light output in a light weight, compact foot print (18-inch high and one 23 pounds).

Technical Specifications

Light Source:
300W Cool White LED Engine (50,000 hr.)
Features:
Motorized Focus
2 Frost Filter to create wash effects
Motorized Zoom: 9~28-degrees
2 Prism FX: Rotating 6-facet Linear & rotating 6-facet Circular
Motorized Iris
Motorized Shutter
0-100% smooth dimming
Various strobe speeds
USB firmware update port
Color Wheels:
Color Wheel 1: 7 dichroic colors + white
Color Wheel 1: 7 dichroic colors (includes CTO, CTB and UV filters)
GOBO Wheels:
GOBO Wheel 1: 7 GOBOS + open
GOBO Wheel 2: 7 GOBOS + open
GOBO Shake Effect
Prism Wheel:
Prism Wheel 1: Rotatable 6-facet Linear
Prism Wheel 2: Rotatable 6-facet Circular
Each Prism is indexable
Frost Filters:
Frost 1: Heavy frost for wash effect
Frost 2: Light frost creates lightly blurred edges for GOBO and Prism FX
Control:
2 DMX Channel Modes: 22/25 Channels
Color LCD display with 6-summary function menu
Control Mode: DMX512 or internal programs
6 Dimming Curve Modes: Standard, Stage, TV, Architectural, Theatre, Stage 2
0-100% smooth dimming
Various strobe speeds
USB firmware update port
With Wired Digital Communication Network
Pan/Tilt:
Pan: 630 degrees
Tilt: 270 degrees
16-bit fine Pan & Tilt
Connections:
DMX Connections: 3-pin & 5-pin XLR In/Out
Power Connections: PowerLock In/Out to daisy chain power
RJ45 In/Out connections for ArtNet and KlingNet
Electrical:
Multi-voltage operation: AC 90-240V, 50/60Hz
Max power consumption: 380W
Dimensions & Weight:
Dimensions (LxWxH): 7.6” x 11” x 18” / 195x278x457mm

Weight: 23 lbs. / 10.4 kg.
