AtlasIED AA35G 3-Input, 35-Watt Mixer Amplifier With Global Power Supply(Atlasied Aa35g 3 Input 35 Watt Mixer Amplifier With Global Power Supply)

AtlasIED AA35G 35W 3‑Input Mixer Amplifier with Global Power Supply

The AtlasIED AA35G is a compact yet powerful 35 W mixer amplifier designed for commercial paging, background music (BGM), and music-on-hold systems. Featuring a front-panel balanced mic/line input (with phantom power capability) and two stereo auxiliaries, it accommodates microphones, VOIP devices, CD players, and more. The unit’s VOX or external switch muting ensures smooth paging transitions, while recessed bass and treble controls offer tailored audio tuning.

Outputs are compatible with 8 Ω, 70.7 V, and 100 V speaker systems, plus a secondary Zone 2 output for multifunction deployment. Its universal power supply (110–240 VAC) supports international setups, and LED indicators provide clear monitoring of signal, clipping, and power status. The AA35G’s compact rack-ready design and robust construction make it ideal for professional installations in offices, retail, hospitality, and institutional environments.

Key Features

• Three Inputs: Balanced mic/line with phantom + two stereo aux (RCA)
• 35 W Multi‑Load Output: Supports 8 Ω, 70.7 V, and 100 V speaker lines
• Priority Muting: VOX or contact‑closure for paging control
• Universal Power Supply: Works on 110–240 VAC globally
• Tone & Level Controls: Front-panel bass/treble ±10 dB; individual and master level knobs

Technical Specifications

• Dimensions: 8.25″ W × 3.85″ H (w/feet) × 12.25″ D
• Net Weight: 8.2 lbs; Shipping Weight: ~10.6 lbs
• Frequency Response: 50 Hz–20 kHz
• Connectors: Phoenix (mic/line), RCA (aux)
• Outputs: 8 Ω, 70.7 V, 100 V, plus 1 W/600 Ω Zone 2
• Indicators: Signal presence, clip, and power LEDs
• Listings: UL 60065, RoHS compliant
• Warranty: 36 months from date of purchase

What’s Included in the Box

• 1 × AtlasIED AA35G mixer amplifier (with rack ears pre-installed)
• 1 × IEC power cord
• 1 × Owner’s manual and warranty documentation
