Audio-Technica AT-XP3 DJ Cartridge XP/VM95 Series Replacement Stylus(Audio Technica At Xp3 Dj Cartridge Xp Vm95 Series Replacement Stylus)

Audio-Technica AT-XP3 DJ Cartridge XP/VM95 Series Replacement Stylus

The Audio-Technica AT-XP3 DJ Cartridge is engineered specifically for professional DJs who demand superior sound quality and reliability from their gear. This cartridge is designed with a highly-rigid polyphenylene sulfide (PPS) and glass fiber body that ensures durability and precise performance. With a tracking force range of 2 to 4 grams, and an impressive output level of 5.5 mV, the AT-XP3 delivers dynamic and high-fidelity sound that faithfully reproduces the nuances of your music. Its 0.6 mil conical bonded stylus offers accurate tracking of the record groove, providing a dependable performance that DJs can count on during their sets. Additionally, its compatible design with any XP or VM95 Series replacement stylus offers users versatile options for different applications and budgets.

For DJs looking to elevate their sound experience, the AT-XP3’s carbon fiber-reinforced ABS cantilever with nylon wire suspension ensures long-lasting use and precise tracking with excellent channel separation. This allows for clean, clear audio with great fidelity. The design of the cartridge allows maximum visibility of the stylus tip to ensure seamless use during live performances.

Key Features

• 0.6 mil conical bonded stylus tip
• Highly-rigid polyphenylene sulfide (PPS)/glass fiber body
• 5.5 mV high-level output
• Tracking force of 2.0 to 4.0 grams (3.0 grams standard)
• Durable carbon fiber-reinforced ABS cantilever and nylon wire suspension ensure precise tracking
• Design offers maximum visibility of the stylus tip
• Great tracking and channel separation for high-fidelity sound
• Compatible with any XP or VM95 Series replacement stylus

Specifications

• Frequency Response: 20-18,000 Hz
• Channel Separation: 20 dB at 1 kHz
• Vertical Tracking Angle: 20°
• Vertical Tracking Force: 2.0-4.0 g (3.0 g standard)
• Stylus Construction: Bonded round shank
• Recommended Load Impedance: 47,000 ohms
• Coil Impedance: 6.7 k ohms (1 kHz)
• Recommended load capacitance: 100 to 200 pF
• Output: 5.5 mV (1 kHz, 5 cm/sec.)
• Channel Balance: 2.0 dB (1 kHz)
• Stylus Shape: 0.6 mil conical
• Cantilever: Carbon-fiber reinforced ABS
• Mount: Half-inch
• Weight: 6.2 g (0.22 oz)
• Dimensions: 17.2 mm H × 17.8 mm W × 28.3 mm D
• Replacement Stylus: ATN-XP3

Package Contents

• Two 11 mm installation screws
• Two 8 mm installation screws
• Two washers
• Two nuts
• Non-magnetic screwdriver
