BASSBOSS MFLA-MK3 3200W Dual 2-Way 12-Inch Powered Line Array Speaker(Bassboss Mfla Mk3 3200w Dual 2 Way 12 Inch Powered Line Array Speaker)

AT312 Loudspeaker: Where Impeccable Audio Quality Meets Powerful Performance
The BASSBOSS MFLA-MK3 3200W Dual 2-Way 12-Inch Powered Line Array Speaker is a perfect combination of high-fidelity sound quality, studio reference monitor accuracy and the ability to cover a dance floor or a small festival stage. By replicating the theoretical ideal of a single, infinitely small point, this 3-way Active co-axial point-source loudspeaker delivers outstanding resolution and imaging that will surpass your expectations. The lows are handled by two 12” neodymium woofers with 4” voice coils, while the neodymium co-axial 12” woofer and tweeter combination produces the mids and highs. Thanks to the comprehensive processing and perfect alignment, the AT312 delivers an unparalleled audio experience.

Experience Enhanced DSP and Powerful Amplification with MK3 Amp Update
The MK3 series comes with all-new amplifiers that offer more power and higher output voltages for greater impact. The total power has increased, with a substantial power allocation to woofers. The new 96kHz DSP offers eight pushsummary presets, and up to 100 presets can now be stored in the DSP and loaded via LAN. The DSP programming includes meticulously tuned equalization, high-pass and low-pass filters, multiple protection systems, and limiters that prevent driver overload in as many ways as possible.

ControlBASS Software: The Perfect Partner for AT312 Loudspeaker
ControlBASS software supports an unlimited number of possible BASSBOSS-developed or customized user presets, which integrate seamlessly and coherently with other BASSBOSS products for perfect setups. Plus, the latest in DSP programming developments can be added via easy remote updating. Experience tear-inducing clarity and the best of hi-fi sound quality combined with studio reference monitor accuracy – all in one powerful package.

Key Features

• Line array system with high output capability
• Requires fewer units compared to other systems
• Equipped with Neodymium 12” woofers and 3” VC compression drivers
• Features fixed-hinge flyware for easy deployment
• Can be used for ground-support deployment
• Comes with DSP-equipped 3200 Watts of amplification
• Amplification can be controlled remotely
• Horizontally symmetrical design
• Dual 12” woofers for enhanced low-frequency performance
• Isophasic high-frequency wave guides for precise sound dispersion

Technical Specifications

Loudspeaker Description
Horizontally Symmetrical 2-way Dual 12”, Self-powered, Vented, direct-radiating Line Array Element with Pressure-Phase Distributed midrange loading and isophasic high-frequency wave guides.
Frequency Response (±3 dB)
60 – 18,000Hz
Maximum Sustained Output
136dB
Max SPL (Peak)*
142dB
Nominal Dispersion (H° x V°)
120 Horizontal, Array Dependent vertical
Amplification
3200 Watts Class D
Processing
Integrated comprehensive DSP. 96kHz sampling rate with 8 pushsummary presets. All presets include high pass filters, low pass filters, phase alignment, equalization and multi-stage limiting. Storage apacity for up to 100 presets
Electrical Connector Amp
Neutrik powerCON True 1 TOP – IP65 rated waterproof connectors
Electrical Connector Mains
Linking Cable, True 1 TOP – Mains Connector Ordered Separately
Voltage Operating Range
100-240V AC, 50-60Hz (Auto-sensing, auto switching universal supply)
Current Draw 120V
4.6 Amps (Nominal)
Current Draw 240V
2.3 Amps (Nominal)
Signal Input Connector
XLR-F
Signal Output Connector
XLR-M (direct pass-through only)
Transducer Low Frequency
2 x 12 in. diameter (300mm) Neodymium motor woofer with 3.5 in. (88mm) voice coils, waterproof cone
Transducer High Frequency
2 x 3 in. (76mm) diameter diaphragm compression drivers with 1.4” (35mm) exits mounted to isophasic wave guides
Cabinet Construction
CNC machined 15mm Birch plywood with extensive bracing and dado joinery. External flyware and linking mechanism with 2 x integrated Handles
Exterior Finish
High-pressure, bonded polyurea coating. Rugged, waterproof. Textured black
Grille
Perforated, powder-coated steel
Dimensions (HxWxD)
16.125 in. x 40.5 in. x 20.375 in. (Including Flyware)
Net Weight
104 lbs
Shipping Weight
130 lbs
What’s Included
Loudspeaker, 4 x 10mm ball-lock pins, manual, and linking power cable
Optional Covers
Multi-box soft covers for up to 4 cabinets when on a rolling cart
Optional Dollies
Aluminum Transport and Deployment Cart for transporting up to 5 cabinets or 4 cabinets and 1 bumper
Optional Hardware
Rigging Frame/Bumper Bar, Interlink Hardware for VS21 subwoofer
True Specifications
Our forward-thinking approach means that we never rest on our laurels. As we continue to innovate and refine our technology, our specifications will evolve. We’re committed to constantly pushing the boundaries and raising the bar.
*Peak output is calculated using “industry standard” techniques. These calculation methods create theoretical specifications that are inflated over what can actually be achieved. BASSBOSS real world output specifications are provided as “Maximum Sustained Output” ratings, which reflect actual measured, continuous output levels.
