Blizzard Lighting IRiS ICON 2.9 Indoor Video Wall Panel, Nationstar 1515 LEDs, 2.9mm(Blizzard Lighting Iris Icon 2 9 Indoor Video Wall Panel Nationstar 1515 Leds 2 9mm)

Blizzard Lighting IRiS ICON 2.9 Indoor Video Wall Panel, Nationstar 1515 LEDs, 2.9mm

IRiS ICON indoor LED video panels fuse industry-leading processing electronics with dozens of improvements. IRiS ICON panels are in the perfect locking position as soon as you take them out of the case, and lock together with a quick flick of the thumb. We also added one-touch retractable metal corner protectors, blackout gaskets & ground support locks all within its ultra lightweight frame. With room for eight 500x500mm IRiS ICON 2.6 or eight ICON 2.9 panels each, even our ATA-spec roto-molded road cases are better than ever. Experience the simple bliss of self-aligning magnetic casters, which makes stacking cases for transport a breeze.

Key Features

• NovaStar A8s receiving card
• Die cast aluminum
• Front or back maintenance
• Corner protectors
• Ground support locks
• Blackout gaskets
• Quick-thumb locking
• Certifications: FCC, ETL, CE, RoHS
• 7-year limited warranty
• NationStar 1515 LEDs (100,000 hours)
• Panel size: 500 x 500 mm
• Pixel pitch: 2.6 mm / 2.9 mm
• Resolution: 168 x 168 (2.6) / 192 x 192 (2.9)

Technical Specifications

IP40 (front) / IP21 (rear)
Installed receiving card
Novastar A8S
Die cast aluminum
Front or back maintenance
Corner protectors
Ground support locks
Blackout gaskets
Quick-thumb locking
Certifications
FCC, ETL, CE, RoHS
Curvature
-9
Viewing angle
140 / 140
Optimal viewing distance
2.9 – 29.0 meters
Working temp
-10~+40 C
Working humidity
10% – 90% RH
Module Specs
Module quantity
2 x 2
Resolution
84 x 84
Pixel quantity
7,056
Dimensions
250 x 250 mm
Optical
Nationstar 1515 LEDs
Pixel pitch
2.9 mm
Resolution
168 x 168
Pixel quantity
28,224
Pixel density
112,896 dots/m2
Scan mode
1/21
Brightness
1000 nit
Contrast
5,000:1
Color depth
14 bit
Grayscale
22 bit+ / Clearview
Refresh rate
3,840 Hz
HDR
HDR10-Optima / HLG
Power
110~220VAC, 50/60 Hz
Input power
662.5 W/m2
Avg. power consumption
176 W/m2
Max. power consumption
530 W/m2
Dims & Weight
19.7” L x 19.7” W x 2.84” H
14.6 lbs
