Connectronics HDMI-20-01 18G High Speed Ethernet 4K/60Hz 4:4:4 Male To Male HDMI 2.0 Cable, 3 Foot(Connectronics Hdmi 20 01 18g High Speed Ethernet 4k 60hz 444 Male To Male Hdmi 2 0 Cable 3 Foot)

Connectronics HDMI-20-01 18G High Speed Ethernet 4K/60Hz 4:4:4 Male to Male HDMI 2.0 Cable, 3 Foot

The Connectronics HDMI 2.0 series is the latest version of high speed with ethernet cable built to support the evolution of 4K compatible HDMI hardware. The HDMI 2.0 standard brings support for 4K@50/60, (2160p) which quadruples the current 1080p/60 standard and brings with it 18 Gbps of physical bandwidth, and conforms to HDCP 2.2 specs. HDCP 2.2 is a technology designed to prevent illegal copying of 4K Ultra HD content. In addition, there is support of 32 channels of audio at sample rates up to 1536kHz sample frequency for the highest clarity in audio available. The Connectronics HDMI 2.0 series cable is also capable of simultaneous delivery of dual video streams and multi-stream audio to multiple users (up to four) where hardware supports these features.

Key Features

• High Speed HDMI Cable with Ethernet
• Supports 4K@50/60, (2160p) as well as High-Frame Rate 2D Content
• Supports Dual Video Streams
• Supports the Highest Possible Frame Rates
• Supports 21:9 Aspect Ratio

Technical Specifications

HDMI cable version
HDM 2.0
Physical Bandwidth
18 Gbps (with High Speed cable).
Maximum Resolution (2D)
4K (4096×2160) @ 60 Hz (4:4:4)
Maximum Color Depth
48 bits (at 4K)
HDCP & DDC
HDCP 2.2 Fully Support bi-directional EDID and HDCP communication.
Video Bandwidth
6Gbps /x 3 Channel (max)+ Clock.
Resolution
PC: WUXGA 1920 x 1200, HDTV : 480p, 720p, 1080i and 1080p deep color, 4K(60P), 3D Full HD 1920 x 1080p.
Connector Type
HDMI type A.
HDMI Cable Type
28AWG, 26AWG and 24AWG copper wire
HDMI Cable Length
3ft /6ft /10ft /15ft
HDMI Cable Outer Diameter
8.5mm
Jacket Outer Material
PVC/TPU
Differential Input
100 ohm
