Crown DCi2x600 600W 2-Channel 70V/100V Analog Power Amplifier(Crown Dci2x600 600w 2 Channel 70v 100v Analog Power Amplifier)

Crown DCi 2|600 Two-Channel, 600W @ 4Ω Analog Power Amplifier with 70V/100V Support

The Crown DCi 2|600 is a high-performance, two-channel analog power amplifier delivering 600 watts per channel at 4 ohms. Engineered with Crown’s proprietary DriveCore™ technology, this amplifier offers exceptional audio quality and reliability, making it an ideal choice for professional installations in various environments, including commercial and entertainment venues.

Designed with versatility in mind, the DCi 2|600 supports direct drive constant voltage outputs of 70V and 100V, eliminating the need for additional transformers and simplifying system configurations. Its compact form factor ensures seamless integration into standard equipment racks, while its energy-efficient operation aligns with modern sustainability requirements.

The DCi 2|600 is equipped with advanced features that provide system integrators with the flexibility required for challenging installed sound applications. Its robust construction and adherence to the industry’s highest quality standards continue Crown’s tradition of leadership in professional and commercial power amplifier technology.

Key Features

• Two-channel amplifier with 600W per channel at 4 ohms
• Supports 70V and 100V direct drive for constant voltage systems
• Proprietary DriveCore™ technology for superior audio performance
• Energy-efficient design reduces operational costs
• Compact size for easy integration into standard racks

Technical Specifications

Output Channels: 2
Frequency Response (8Ω, 20Hz – 20kHz): ±0.25dB
Total Harmonic Distortion (at full rated power, 20Hz – 20kHz): 0.35%
Damping Factor (20Hz to 100Hz): >1000
Load Impedance (Stereo/Dual Mode): 2Ω – 16Ω; 70Vrms and 100Vrms
Load Impedance Bridge Mono: 4Ω – 16Ω; 140Vrms and 200Vrms
Cooling: Continuously variable speed forced air, front to back airflow
Maximum Fan Noise (re dBA SPL @ 1M): 45
Required AC Mains (±10%): 100V-240V ~ 50/60Hz
Power Connector: 15A IEC
Dimensions (W x H x D): 19 in x 3.5 in x 14.25 in
Weight: 18.8 lbs

What’s Included

• Crown DCi 2|600 Two-Channel, 600W @ 4Ω Analog Power Amplifier with 70V/100V Support
• Power Cord
• User Manual
