Crown DCi8x300DA 300W 8-Channel Power Amplifier With Dante(Crown Dci8x300da 300w 8 Channel Power Amplifier With Dante)

Crown DCi 8|300DA Eight-Channel Power Amplifier with Dante™ / AES67 Networked Audio

The Crown DCi 8|300DA is an advanced eight-channel power amplifier delivering 300W per channel at 4Ω, designed to meet the rigorous demands of modern audio installations. Integrating proprietary DriveCore® technology, this amplifier ensures exceptional efficiency and audio quality, making it an ideal choice for venues requiring reliable and high-performance sound reinforcement.

Equipped with Dante™ and AES67 networked audio capabilities, the DCi 8|300DA simplifies complex installations by allowing seamless audio signal distribution over standard IP networks. This feature provides flexibility and scalability, accommodating various system configurations and future expansions. Additionally, the amplifier’s compliance with EN 54-16 standards makes it suitable for life safety applications, ensuring dependable performance in critical environments.

The DCi 8|300DA boasts a robust design capable of driving a wide range of speaker loads, including 2Ω, 4Ω, 8Ω, 16Ω, as well as 70V and 100V systems. Its high-powered DSP includes JBL speaker tunings, network control and monitoring, and advanced features such as LevelMAX limiters, input/output EQ, crossover, delay, and matrix routing. These capabilities enable precise audio customization and optimization, ensuring superior sound quality tailored to specific installation requirements.

Key Features

• Eight channels with 300W output per channel at 4Ω
• Integrated Dante™ / AES67 networked audio for streamlined installations
• Supports 2Ω to 16Ω, 70V, and 100V speaker loads
• High-powered DSP with JBL speaker tunings
• Network control and monitoring capabilities
• EN 54-16 compliant for life safety applications
• Proprietary DriveCore® technology for enhanced efficiency and audio quality

Technical Specifications

Output Channels: 8
Frequency Response (8Ω, 20Hz – 20kHz): ±0.25dB
Total Harmonic Distortion (at full rated power, 20Hz – 20kHz): 0.35%
Damping Factor (20Hz to 100Hz): >1000
Load Impedance (Stereo/Dual Mode): 2Ω – 16Ω; 70Vrms and 100Vrms
Load Impedance Bridge Mono: 4Ω – 16Ω; 140Vrms and 200Vrms
Cooling: Continuously variable speed forced air, front to back airflow
Maximum Fan Noise (re dBA SPL @ 1M): 47
Required AC Mains (±10%): 100V-240V ~ 50/60Hz
Power Connector: 20A IEC
Dimensions (W x H x D): 19 in x 3.5 in x 14.25 in
Weight: 23.5 lbs

What’s Included

• DCi 8|300DA Power Amplifier
• IEC Power Cord
• User Manual
