Elation Design LED 36 Tri-Brick 36W Tri-Color LED Fixtures (Used)(Elation Design Led 36 Tri Brick 36w Tri Color Led Fixtures Used)

Elation Design LED 36 Tri-Brick 36W Tri-Color LED Fixtures (Used)

Used: No problem with function but may have signs of heavy usage.

36W DLED Brick 12 x Tri Color 3W LEDs

Key Features

• 12 x “Tri-Color” 3W LEDs – (Uses 3-in-1 TRI LED system for superior color mixing – No three color shadows)
• Seamless RGB color mixing
• Infinite Color possibilities
• Compact Design
• Standard 45 Lens Kit, 48 Beam Angle
• 2720 LUX @ 1 meter
• 350 LUX @ 3 meters
• Long Life L.E.D. (rated at 100,000 Hours)
• Built-in Power Supply and DMX 512 Control

Technical Specifications

CONTROL SPECIFICATIONS
USITT-DMX 512
3, 4, 12 OR 15CH operation modes
4 Button Electronic Menu
3 & 5 pin XLR in/out
IEC Power in/out
CONTROL FEATURES
Master/ Slave auto program and music trigger
8 built-in programs with Speed control
Strobe effect (1-18 flashed per second)
Control each L.E.D. independently
0-100% Dimming
POWER SUPPLY
Multi-voltage: 100-240V AC, 50/60Hz
On/Off Power switch
Fan cooled
RIGGING
Mounting bracket and safety eye-hook installed
DIMENSIONS & WEIGHT
(LxWxH): 16.3” x 9” x 3.15” / 415 x 230 x 80mm
9.5 lbs. / 4.3 kgs.
cETLus Approved
