EMG 40CS 5-String Ceramic/Steel Extended Range Bass Humbucker(Emg 40cs 5 String Ceramic Steel Extended Range Bass Humbucker)

EMG 40CS Extended Range Bass Humbucker – Powerful Ceramic & Steel Punch

The EMG 40CS is a modern humbucker designed for bass players seeking a robust tone with controlled high frequencies. Featuring dual coils loaded with ceramic and steel magnets, this pickup delivers warmth and punch, complemented by a smooth top end and substantial output. Whether you’re performing on stage or recording in the studio, the 40CS ensures your bass lines stand out with clarity and depth.

Designed specifically for five-string bass guitars, the EMG 40CS fits perfectly into a 4-inch (102mm) extended housing. Its construction not only enhances tonal quality but also ensures durability and longevity. The pickup’s quiet preamp minimizes noise when not in use, allowing for a cleaner sound during performances and recordings.

Installation is straightforward with EMG’s exclusive solderless wiring system, making it accessible even for those new to modifying their instruments. This user-friendly approach means you can upgrade your bass’s sound without the need for professional assistance, getting you back to playing with minimal downtime.

Key Features

• Dual-coil humbucker with ceramic and steel magnets
• Warm, punchy tone with a smooth high-end
• Designed for 5-string bass guitars
• Quiet preamp reduces noise when idle
• Easy installation with solderless wiring system

Technical Specifications

Colors Available: Black, Ivory, White
Logo Color: Silver
Magnet Type: Ceramic and Steel (C/S)
Resonant Frequency: 3.75 kHz
Output Voltage (Finger, Thumb): 2.50 V
Output Voltage (Thump): 6.00 V
Output Noise (60 Hz): -108 dBV
Output Impedance: 10 kΩ
Current (@9V): 230 µA
Battery Life: 1000 hours
Maximum Supply: 27 V DC

Dimensions: 4.00″ x 1.50″ x 0.88″
Maximum Recommended String Width: 3.00″

What’s Included

• 1 EMG 40CS Pickup
• 1 25k volume pot
• 1 25k tone pot
• 1 battery bus
• 1 stereo output jack
• 1 pair mounting screws
• 1 pickup cable
• 2 connect cables
• 1 output cable
• 1 battery cable
