Fiberplex SFP-MC24XC-3131-2 SFP Optical Multimode 1.25 Gbps 1310nm Transceiver(Fiberplex Sfp Mc24xc 3131 2 Sfp Optical Multimode 1 25 Gbps 1310nm Transceiver)

Fiberplex SFP-MC24XC-3131-2 SFP Optical Multimode 1.25 Gbps 1310nm Transceiver

The FiberPlex Technologies SFP-MC24XC-3131-2 Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The SFP transceivers are high-performance , cost effective modules supporting a host of data rates and distances. They are RoHS compliant and lead-free. These optical modules are designed for digital data applications and are not recommended for digital video applications due to SMPTE encoding that may cause pathological signal errors.

Key Features

• Duplex LC connector
• Hot-pluggable SFP footprint
• RoHS compliant and Lead Free
• Metal enclosure for lower EMI
• Single +3.3V power supply
• Low power dissipation <800mW
• SFP MSA SFF-8074i Compliant

Technical Specifications

Voltage Range
Min – 3.13; Typ. – 3.3; Max – 3.47; Unit – VDC
Supply Current
250 mA
Depth
2.23 in
Height
0.47 in
Width
0.54 in
Product Weight
0.05 lbs
Operating Temperature (Maximum)
158 F
Operating Temperature (Minimum)
32 F
