Liberty AV COMET-UPAAF-M USB 2.0 Cable, Black(Liberty Av Comet Upaaf M Usb 20 Cable Black)

The Liberty AV COMET-UPAAF-M USB 2.0 Cable, Black is designed to extend USB 2.0 signals using a plenum-rated Active Optical hybrid cable assembly. By incorporating active circuitry within the permanent USB connectors, this solution enables the transmission of USB signals over fixed-length cables ranging from 8 meters to 40 meters. These cables can supply USB 2.0 power up to 0.5W over distances of up to 25 meters, supporting data transfer rates of up to 480Mbps. Being a hybrid fiber optic cable, the COMET-UPAAF-M is impervious to electromagnetic (EM) and radio frequency (RF) interference, safeguarding the signal integrity and ensuring minimal interference with other electronic devices. It’s important to note that the USB A male to A female format deviates from the standard USB-approved configurations. The A to A female connection serves to extend from the Host, with a subsequent USB A-B or A-C cable required on the Client side to establish the appropriate connection. Notably, this cable operates unidirectionally, facilitating communication solely in the conventional USB Host to Client mode. To optimize performance, it is recommended to keep the connecting cable on the Client side under 1 meter in length. Prior to deployment, it is advisable to conduct bench testing to validate the configuration.

Key Features

• USB 2.0 compatibility
• Data transfer speed of 480Mbps
• Resistant to EMI/RFI interference
• Plenum rated with small diameter
• Does not require external power source
• Provides 100mA at 5VDC
• Ideal for USB extension and routing
• Suitable for USB peripheral control
• Supports video over USB
• Perfect for boardroom, collaboration, and education purposes

Technical Specifications

Part Numbers + Part Description + Cable Length
COMET‐UPAAF‐08M, USB 2.0 AOC AM‐AF CMP 8M, 8 meters / 26 feet
COMET‐UPAAF‐10M, USB 2.0 AOC AM‐AF CMP 10M, 10 meters / 33 feet
COMET‐UPAAF‐15M, USB 2.0 AOC AM‐AF CMP 15M, 15 meters / 50 feet
COMET‐UPAAF‐23M, USB 2.0 AOC AM‐AF CMP 23M, 23 meters / 75 feet
COMET‐UPAAF‐30M, USB 2.0 AOC AM‐AF CMP 30M, 30 meters / 100 feet
COMET‐UPAAF‐40M, USB 2.0 AOC AM‐AF CMP 40M, 40 meters / 130 feet

I/O Connections
USB
Male to Female USB Type A connectors, Gold Plated contacts

Supported Signals
USB
USB 2.0 High Speed 480Mbps
Formats Supported
Enumeration, Interrupt, Bulk, Isochronous
Power
Up to 25m supports 0.5W (5V 100mA), over 25m may need power inserters
Maximum Bandwidth
480Mbps

Cable Construction
USB Hood Material
Black Anodized Plated ABS
Male USB Hood Dimensions
34.5mm x 18.5mm x 9.20mm. Strain relief is 7.0mm
Female USB Hood Dimensions
41.5mm x 19.6mm x 10.0mm. Strain relief is 7.0mm
Fiber Jacket Material
Fluoropolymer (FEP)
Cable Construction
Hybrid GOF (Glass Optical Fiber) OM2 and 24 AWG Copper
Overall Cable Diameter
4.8 mm (0.189‐inch)
Minimum Bend Radius
Unloaded: 48 mm (1.89”), Loaded: 96mm (3.78”)
Maximum Tensile Load
20 kg (44 lbs.)

Environmental Requirements
Operating Temperature
0° to 50° C (+32° to +122° F)
Operating Humidity
20% to 85%, Non‐condensing
Storage Temperature
‐30° to 75° C (‐22° to +122° F)
Storage Humidity
20% to 85%, Non‐condensing

Power and Regulatory
Power Supply
USB BUS power supplied by Host/Client
Power Consumption
<0.50W both sides when not used to power remote client
Power Delivery
1 USB 2.0 Power Unit = 100mA@5VDC to 25m
Regulatory
NEC® rated CMP, CEC rated CMP, RoHS Compliant, CE, EU CPR Eca
EMI/EMC
FCC Class B, CISPR32
Laser
Class 1 840‐860nm, 700µW

Other
Warranty
3 years
