Reloop RP-4000 MK2 Direct Drive High Torque Turntable(Reloop Rp 4000 Mk2 Direct Drive High Torque Turntable)

Reloop RP-4000 MK2 Direct Drive High Torque Turntable

The RP-4000 MK2 is a solid DJ turntable for advanced users. The new MK2 version comes with several improvements, including a newly developed top panel and reworked metallic summarys with enhanced feel as well as a variety of functions.

REVERSE FUNCTION, PITCH RESET AND EXTENDIBLE NEEDLE ILLUMINATION
Additional features, such as reverse play and pitch reset, offer all DJs direct control of their turntable. With the push of a summary the aluminium target light can be extended, so that the needle position can be seen in dark surroundings.

PRECISE MOTOR CONTROL WITH 3 SPEEDS
The precision-engineered die-cast platter is accelerated by a powerful motor with a high-torque direct drive of more than 1.8 kg/cm. The precise motor control with 3 speeds (33 1/3, 45 & 78 rpm) allows for the RP-4000 MK2 to play back any record. The pitch section with a selectable range of +/-8% and +/-16%, respectively, is suitable for the finest pitch adjustments.

STATICALLY BALANCED S-SHAPED TONE ARM
The RP-4000 MK2 features a statically balanced s-shaped tone arm with hydraulic lift and anti-skating mechanism. Via the universal connection for pick-up systems (SME) a large number of pick-up systems can be connected.

WITH PICK-UP AND HEADSHELL
The RP-4000 MK2 comes with the high-quality OM Black pick-up, handmade by Ortofon in Denmark, pre-fitted to a headshell ready for immediate playback.

NEWLY DEVELOPED TOP PANEL AND STURDY HOUSING DESIGN
The new deep black metallic top panel construction is equipped with metallic summarys for start/stop, platter speed, pitch control, reverse function and tempo reset. The improved touch upon hit offers a clear haptic feedback. The sturdy construction with optimized damping features and shock-absorbing feet improve isolation from unwanted vibrations.

Key Features

• NEW in the MK2 version:
• Newly developed top panel and reinforced housing construction
• Reworked metallic summarys with improved feel & tactile response
• Precision Pitch with selectable ranges of +/-8 % & +/-16 %
• Tempo reset (Quartz Lock) feature
• Superior finish in deep black metallic
• Quartz-driven DJ turntable with high-torque direct drive
• Designed for professional use
• Powerful brushless DC motor with more than 1.8 kg/cm torque
• Precise motor control with 3 speeds selectable (33 1/3, 45 & 78 rpm)
• Reverse function: switch for forward/reverse playback
• Precision-engineered die-cast aluminium platter with stable rotation
• Statically balanced s-shaped tone arm with hydraulic lift and anti-skating mechanism
• Universal connection for pick-up systems (SME)
• Extendible needle illumination
• Shock-absorbing feet for vibration isolation
• Sturdy, heavy construction with optimized damping features
• Prepared for dust cover (available as optional accessory)
• Incl. slipmat, removable headshell and ready-mounted OM Black pick-up made by Ortofon

Technical Specifications

Turntable:
Type: direct drive turntable
Drive: quartz-driven high-torque direct drive
Motor: 8-pol., 3-phase, brushless DC motor
Turntable speeds: 3 speeds, manual (33 1/3, 45, 78 rpm)
Starting torque: > 1.8 kg/cm
Brake time: < 1 sec.
Start-up / rpm change: < 1 sec.
Wow and flutter: < 0.2 % WRMS
Signal-to-noise ratio: > 50 dB (DIN-B)
Brake system: electronic brake
Platter:
Material: aluminium die-cast
Diameter: 332 mm
Tone arm:
Type: universal, statically balanced, s-shaped
Effective length: 230.5 mm
Overhang: 16 mm
Tracking angle error: < 3 deg
Applicable pick-up weight: 3.5 – 8.5 g (incl. headshell 13 – 18 g)
Anti-skating range: 0 – 7 g
Connections:
1x PHONO out (gold-plated), 1x GND
General:
Power supply: AC 115/230 V, 60/50 Hz (EU/US), AC 100 V, 50/60 Hz (JP)
Power consumption: 12 W
Dimensions: 450 (w) x 352 (d) x 144 (h) mm
Weight: appr. 9.8 kg
Included accessories:
Platter, OM Black pick-up system (by Ortofon), headshell, slipmat, counterweight, power cord, instruction manual
