Ubiquiti UA-G2-Pro Access Control Hub Outdoor PoE(Ubiquiti Ua G2 Pro Access Control Hub Outdoor Poe)

Ubiquiti UA-G2-Pro Access Control Hub with PoE and NFC

The Ubiquiti UA-G2-Pro Access Control Hub is an advanced networking and security device designed for use in outdoor environments. Ideal for enhancing building access management, it features a robust polycarbonate and glass enclosure, offering high weatherproofing (IP55) and reliable performance in challenging conditions. The hub connects via PoE and includes a camera with a wide-angle view, a microphone, and a speaker, making it a great choice for security-conscious installations. It also supports NFC and BLE connectivity for efficient access control integration.

Key Features

• PoE-powered for easy installation
• Supports NFC for seamless access control
• Wide-angle camera for enhanced visibility
• ESD/EMP protection for added durability
• IP55-rated for outdoor use

Technical Specifications

Dimensions: 6.3 x 1.59 x 1.6 inches (160 x 40.4 x 40.55 mm)
Weight: 4.8 oz (136 g)

Enclosure Material: Polycarbonate, glass
Mounting Material: Aluminum alloy
Mounting: Wall, gang box
Weatherproofing: IP55

Networking Interface: (1) GbE RJ45 port
Connectivity: BLE 4.2, NFC
Power Method: PoE
Max Power Consumption: 6W

Camera View Angle: H: 96.67°, V: 123.15°, D: 153.11°
Microphone: Yes
Speaker: 4 ohm, 1.5W
LEDs: R/G/B/W/Amber

NFC Frequency: 13.56 MHz
NFC Read Range: < 30 mm
NFC Technology: ISO/IEC 14443A / 14443B / 15693 / 18092 (Ecma 340), MIFARE Classic / MIFARE DESFIRE, Sony FeliCa™ (ID only)

Operating Environment: Outdoor use
Ambient Operating Temperature: Device: -30 to 45°C (-22 to 113°F), Display: -10 to 45°C (14 to 113°F)
Ambient Operating Humidity: 5 to 90% noncondensing

Certifications: CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
PoE Cabling Requirements: 26 AWG (0.13 mm²) for patch cords; 24 AWG (0.21 mm²) for horizontal or riser cable

UL 294 Level: Destructive attack: Level I, Line security: Level I, Endurance: Level I, Standby power: Level I
