Ubiquiti UniFi nanoHD – Compact Dual-Band Wi-Fi 6 Access Point

Ubiquiti UniFi nanoHD – Compact Dual-Band Wi-Fi 6 Access Point

The Ubiquiti UniFi nanoHD is a compact, high-performance wireless access point designed for demanding network environments. It features a sleek, modern design and delivers exceptional performance with its dual-band radios, supporting the latest Wi-Fi standards (802.11ac Wave 2) and offering a combined aggregate throughput rate of over 2 Gbps. The UniFi nanoHD is ideal for deployment in high-density environments such as offices, schools, and hospitality settings, where it can efficiently handle a large number of connected devices.

The UniFi nanoHD features a 4×4 MIMO configuration on the 5 GHz band and a 2×2 MIMO configuration on the 2.4 GHz band. This allows it to deliver strong signal strength and improve overall network efficiency, even in congested environments. Additionally, the UniFi nanoHD supports advanced features like MU-MIMO (Multi-User, Multiple-Input, Multiple-Output) technology, which allows it to communicate with multiple devices simultaneously, further improving network performance.

Key Features

• Delivers high-performance Wi-Fi with a combined aggregate throughput rate of over 2 Gbps (802.11ac Wave 2)
• Compact and stylish design for discreet placement
• Dual-band radios with 4×4 MIMO (5 GHz) and 2×2 MIMO (2.4 GHz) configuration
• Supports MU-MIMO technology for improved network efficiency
• Seamless integration with the Ubiquiti UniFi Network application for centralized management
• PoE (Power over Ethernet) compatibility for simplified deployment (802.3af PoE Adapter required, sold separately)

Technical Specifications

Mechanical

• Dimensions: 77 x 77 x 28 mm (3 x 3 x 1.1″)
• Weight: 110 g (3.9 oz)
• Enclosure material: UV-stabilized polycarbonate (PC110U)

Hardware

• Networking interface:
  • (1) SC/APC, ITU-G.984 GPON WAN port
  • (1) GbE RJ45 LAN port
• Management interface: Ethernet In-Band PON
• Power method: 24V Passive PoE (Pins 4, 5+; 7, 8-), 0.3A
• Power supply: UniFi PoE Switch
• Supported voltage range: 20–28V DC
• Max. power consumption: 7W
• Total non-blocking line rate:
  • Downstream: 2.488 Gbps
  • Upstream: 1.244 Gbps
• Normal range of optical module:
  • TX: 1.5 to 5 dBm
  • RX: -8 to -28 dBm
• Button:
  • (1) Factory reset
  • (1) Information
• Ambient operating temperature: -40 to 55° C (-40 to 158° F)
• Ambient operating humidity: 5 to 95% noncondensing
• Certifications: FCC, IC, CE
• LEDs:
  • PON status:
    • (1) Steady white: powered up
    • (1) Blinking white: activity
    • (1) OFF: link down
    • (1) Red: no optical receive power, loss of signal
  • Ethernet:
    • Steady white: link up
    • Blinking white: activity
    • OFF: link down
  • Power: White: ON

Software

• Mode: ONU/ONT layer 2/3 Ethernet switch
• Services: Web server, telnet, NAT, bridging and routing, firewall features, and application passthrough features
• Utilities: Dashboard, monitoring, alarms, and logs
• Other: Remote reset, remote reboot, remote firmware upgrade, VLAN support
• Security: GEM Port Encryption
• Ubiquiti specific features: UISP Mobile App

Fiber

• Operating wavelength:
  • TX: 1310 nm
  • RX: 1490 nm
• Line code: Scrambled NRZ
• Optical interface nominal bit rate:
  • Downstream: 2488.32 Mbit/s
  • Upstream: 1244.16 Mbit/s
• Physical reach: 20 km

Package Contents

• Ubiquiti UniFi nanoHD
• Mounting hardware
• Quick Start Guide
