Ubiquiti UniFi USW-48-POE 48-Port PoE Switch

The Ubiquiti UniFi USW-48-POE is a high-performance, fully managed 48-port switch designed for modern networking needs. Featuring 32 Gigabit Ethernet PoE+ ports and 4 SFP ports, this switch provides reliable performance and scalability for both home and enterprise networks. With 195W of total PoE power available, it’s ideal for powering network devices such as access points, cameras, and phones, all while maintaining efficient, noise-free operation thanks to its fanless design.

Key Features:

• 48 Gigabit Ethernet PoE+ ports
• 4 SFP ports for flexible fiber connectivity
• 195W total PoE power
• Fanless design for silent operation
• Advanced Layer 2 switching features

Technical Specifications:

Dimensions: 442 x 285 x 44 mm (17.4 x 11.2 x 1.7″)
Weight: 4.5 kg (10 lb) without mounting brackets, 4.6 kg (10.2 lb) with mounting brackets
Enclosure material: SGCC steel
Management interface: Ethernet In-Band
Networking interface: (48) GbE RJ45 ports, (4) 1G SFP ports
PoE interface: (32) PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total non-blocking throughput: 52 Gbps
Switching capacity: 104 Gbps
Forwarding rate: 77.38 Mpps
Power method: Universal input, 100—240V AC, 50/60 Hz
Power supply: AC/DC, internal, 240W
Max. power consumption: 45W (excluding PoE output)
Total PoE available: 195W
Max. PoE wattage per port by PSE: PoE+: 32W
Voltage range PoE mode: PoE: 44—57V, PoE+: 50—57V
ESD/EMP protection: Air: ± 16kV, contact: ± 12kV
Shock and vibration: ETSI300-019-1.4 Standard
Ambient operating temperature: -5 to 40° C (23 to 104° F)
Ambient operating humidity: 10 to 90% noncondensing
Certifications: CE, FCC, IC

Switching Features:

• IGMP snooping
• STP / RSTP with priorities and port-level disable
• Port isolation
• Storm control, Voice VLAN, and Port mirroring
• LACP port aggregation and Jumbo frames support

Package Contents:

• UniFi Switch 48 PoE
• Mounting hardware
• Power cord
